2-Piece Ball Valve, 2 in, FNPT, Standard Port, Plated Brass Ball, Bronze
PartAPO7060801
MFG7060801
Description
Apollo™, 7060801, Diversion Ball Valve, 3-Way, Series: 70-600, 2 in Nominal, FNPT End Style, 400 psi CWP Pressure, 500 deg F, Standard Port, Media: Gas/Water, 1-1/2 in Orifice, Lever Operated Actuator, 4.69 in Inlet to Outlet Length, 3.07 in Top to Inlet Center, Bronze Body, Brass Stem/RPTFE Seat Trim, RPTFE/MPTFE Softgoods, Domestic
Price/Availability Accessible On Login
- Blow-out proof stem
- Drilled and tapped mounting pad
The Apollo™ 70-600 series standard port 3-way diversion valve is ideal for making tank selection and fluid transfers simpler. Manufactured with proven ASTM Materials in the US.
| Nominal Size | 2 in |
| End Style | FNPT |
| Port Type | Standard |
| Construction | 2-Piece |
| Material | Bronze |
| Ball Material | Plated Brass |
| Actuator Type | Lever Operated |
| Body Material | Bronze |
| Domestic/Import | Domestic |
| Inlet to Outlet Length | 4.69 in |
| Media | Gas/Water |
| Orifice Size | 1-1/2 in |
| Pressure Rating | 400 psig CWP |
| Series | 70-600 |
| Softgoods Material | RPTFE/MPTFE |
| Temperature Rating | 500 deg F |
| Top to Inlet Center | 3.07 in |
| Trim Material | Brass Stem and RPTFE Seat |
| Brand | Apollo™ |
| Package Width | 8.25 in |
| Package Height | 4.75 in |
| UNSPSC | 40141607 |
| Package Length | 9.5 in |
| Country of Origin | US |
| Manufacturer | Apollo Conbraco |
| UPC | 670750674167 |
| Manufacturer Part Number | 7060801 |
Adjustable Packing Gland
5 Years
ASTM B584-C84400 Body|ASTM B16 Stem|ASTM B283-C37700 Ball|CRN OC10908.5C|Federal Specifications WW-V-35C|MSS SP-110|PROP65: Cancer and Reproductive Harm
Making Tank Selection and Fluid Transfers
