3-Piece Ball Valve, 3/4 in, C, Full Port, Stainless Steel Ball, Bronze
PartNIBCS595YX66EC34
MFGNJ93HE8
Description
NIBCO® Ball Valve, 3-Piece, Series: CS-595-YX-66-EC, 3/4 in Nominal, Solder, 600 psi, 400 deg F, Full Port, Media: Medical Gas, Locking Lever Handle Actuator, Polished Chrome Brass Ball, 13.41 in Inlet to Outlet Length, 2 in Top to Inlet Center, Bronze Body, Silicon Bronze Trim, PTFE/Fluorocarbon Rubber, Domestic
Notice
Price/Availability Accessible On Login- Valve pressure rating 600 psi 41.4 bar non-shock cold working pressure
- Maximum temperature rating 400 deg F
- Blowout-proof stem
- Standard lever handle, optional NIB-SEAL
- Solder end connections
- Dezincification resistant
- This valve is equipped with straight or extended stub ends for brazing in-line
- It may be used for isolation and throttling (half open to full open only)
The NIBCO® bronze ball valve provides bubble-tight shut-off at 600 psi. The 3-Piece valve is ideal for medical gas applications. This valve is equipped with straight or extended stub ends for brazing in-line. It may be used for isolation and throttling (half open to full open only). The 3-Piece valve is repairable in-line. The NIBCO® bronze ball valve provides ease of operation with quarter-turn (90 deg) open to close. The PTFE seat ring and stainless steel ball and stem exhibits high chemical resistance properties and is recommended for many high pressure applications. The 3-Piece valve features solder end connections for easy installation. Options include NIB-SEAL® insulated handle that eliminates condensate. Please refer to NIBCO® technical data sheet, valve selection guide and catalog for engineering and installation information. Choose NIBCO® ball valves for the most specified, versatile and economical valve option in commercial, mechanical and industrial applications. NIBCO® ball valves are backed by the NIBCO® INC. 5-year 125% limited warranty.
| Nominal Size | 3/4 in |
| End Style | C |
| Port Type | Full |
| Construction | 3-Piece |
| Material | Bronze |
| Ball Material | Stainless Steel |
| Actuator Type | Standard Lever |
| Body Material | Bronze |
| Domestic/Import | Domestic |
| Inlet to Outlet Length | 13.41 in |
| Media | Medical Gas |
| Pressure Rating | 600 psi |
| Series | CS-595-YX-66-EC |
| Softgoods Material | PTFE/Fluorocarbon Rubber |
| Temperature Rating | 400 deg F |
| Top to Inlet Center | 2 in |
| Trim Material | Stainless Steel Stem |
| Brand | NIBCO® |
| Package Width | 4.5 in |
| Package Height | 3.25 in |
| UNSPSC | 40141607 |
| Package Length | 16 in |
| Country of Origin | US |
| Manufacturer | NIBCO Inc. |
| UPC | 039923693075 |
| Manufacturer Part Number | NJ93HE8 |
5 Years Limited
ASTM A276 Type 316 Ball|ASTM B584 Alloy C84400 Body|ASTM A449 Grade 5 Body Bolt/Nut|MSS SP-110|NFPA99 and CGA Pamphlet G-4-1|PROP65: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Medical Gas Applications
