Pressure Reducing Boiler Feed Valve, 3/4 in, FNPT, 100 psi, Bronze Body
PartTAC3353
MFG335-3
Description
Taco®, 335-3, Boiler Feed Valve, Pressure Reducing, Series: 335, 3/4 in Nominal, C x NPT End Style, 100 psi Pressure, 212 deg F, 3-3/4 in Inlet to Outlet Length, 3-3/4 in Top to Inlet Center, Bronze Body, White, 3-3/4 in H x 3-3/4 in W Dimensions
Price/Availability Accessible On Login
Documentation
- Fast fill rate on all models
- Exclusive fast fill lever lock
- Built-in check to prevent emptying the system if incoming pressure fails
- Adjustable set pressure of 10 to 25 psi
- Pressure setting adjustment separated from fast fill lever for easy, fast adjustment
- 12 psi factory setting of system side
- Factory Set at 12 psi pressure set point
- Feeds water into a hot water heating system whenever pressure drops below the valves setting
- Union connection with tailpiece is standard
Taco Boiler Feed Valves automatically feed water to a system whenever pressure in the system drops below the pressure setting of the valve. The Dual Control models combine the boiler feed with an in-line pressure relief valve. The built-in check prevents emptying the system if incoming pressure falls. They feature fast fill rates and an exclusive, lockable fast fill lever.
| Nominal Size | 3/4 in |
| End Style | FNPT |
| Body Material | Bronze |
| Color | White |
| Dimensions | 3-3/4 in H x 3-3/4 in W |
| Inlet to Outlet Length | 3-3/4 in |
| Pressure Rating | 100 psi |
| Series | 335 |
| Temperature Rating | 212 deg F |
| Top to Inlet Center | 3-3/4 in |
| Type | Pressure Reducing |
| Brand | Taco® |
| Country of Origin | US |
| Manufacturer | Taco |
| Manufacturer Part Number | 335-3 |
2 Keys and Mounting Kit
1 Year
For Heating
