78BL Flow Balancing Valve, 3/4 in, FNPT, Brass
PartVFPCBVLFTHD34
MFGV00678BLFF
Description
Victaulic® Balancing Valve, Lead Free, Series: 78BL, 3/4 in Nominal, FNPT End Style, 400 psi, -4 to 248 deg F, 0.94 to 12.48 gpm, Media: Water, Handle Actuator, Brass Body, Stainless steel Stem/PTFE Seat Trim, EPDM
Price/Availability Accessible On Login
Documentation
- Shut-off, manual throttling and measuring valve with reduced port
- Shut-off, throttling and measuring ball valve with adjustable memory stop
- EPDM O-ring
| Nominal Size | 3/4 in |
| End Style | FNPT |
| Material | Brass |
| Series | 78BL |
| Actuator Type | Handle |
| Body Material | Brass |
| Flow Rate | 0.94 to 12.48 gpm |
| Media | Water |
| Pressure Rating | 400 psi |
| Softgoods Material | EPDM |
| Temperature Rating | -4 to 248 deg F |
| Trim Material | Stainless steel Stem/PTFE Seat |
| Brand | Victaulic® |
| UNSPSC | 40141600 |
| Manufacturer | Victaulic |
| UPC | 883481585439 |
| Manufacturer Part Number | V00678BLFF |
ANSI/NSF 61|IAPMO Listed
Price/Availability Accessible On Login
Documentation
Victaulic®78BL Flow Balancing Valve, 3/4 in, FNPT, Brass
