Upright Fire Sprinkler Head, Standard Response, 1/2 in, 5.6 K, 175 deg F, White
PartVSH271AES440
MFGS271AES440
Description
Victaulic® FireLock® Upright Sprinkler, Standard Response, Series: V2703, 250 psi, 2-3/8 in Overall Length, 1/2 in, Nominal K-Factor: 5.6 gpm, NPT, 175 deg F, White Painted
Price/Availability Accessible On Login
- K5.6
- 8.1 SI
- Available with Style V9 FireLock™ IGS™ Sprinkler Coupling
These Model V27 standard spray sprinklers are designed to produce a hemispherical spray pattern for standard commercial applications. They are available with either standard or quick response bulb. It is cast with a hex-shaped wrench boss to allow easy tightening from many angles, reducing assembly effort. This sprinkler is available in various temperature ratings and finishes to meet many design requirements. The recessed pendent should be utilized with a Model V27 recessed escutcheon which provides up to 3/4 in of adjustments.
| Thread Size | 1/2 in |
| Nominal K-Factor | 5.6 K |
| Temperature Rating | 175 deg F |
| Type | Upright |
| Color Family | White |
| Activation Type | Standard Response |
| Finish/Color | White |
| Color | White Painted |
| Connection Type | NPT |
| Overall Length | 2-3/8 in |
| Pressure Rating | 250 psi |
| Series | V2703 |
| Brand | Victaulic® |
| UNSPSC | 46191602 |
| Manufacturer | Victaulic |
| UPC | 688304285615 |
| Manufacturer Part Number | S271AES440 |
cULus Listed|FM Approved|VdS Approved|LPCB Approved|CNBOP|CCC|GOST Standard
Commercial
Price/Availability Accessible On Login
Victaulic®Upright Fire Sprinkler Head, Standard Response, 1/2 in, 5.6 K, 175 deg F, White
