Gas Valve, 1/2 x 3/4 in HSI/DSI/Intermittent/Proven Pilot Ignition, 230 Kbtu/hr/cu-ft, Liquid Propane/Natural Gas, 24 V Coil
PartWRG36H32304
MFG36H32-304
Description
White-Rodgers™ Gas Valve, Series: 36H, 1/2 x 3/4 in Nominal, 0.5 psi Pressure, HSI/DSI/Intermittent/Proven Pilot Ignition, 230000 Btu/cu-ft Nominal, Liquid Propane/Natural Gas Gas, 24 V Coil, -40 to 175 deg F, Import
Price/Availability Accessible On Login
- Fast opening
- Electric on/off switch
- Flow straight-thru
- Adjustable regulator
- Quiet operation redundant design
- Inlet/outlet screens
- Tamper resistant screws
- 50/60 Hz
- 0.41 A
- Replaces 36E36-304, the 36H32-304 can also be replaced by 36H32-423
- For intermittent ignition systems (Direct Ignition, proven Pilot, HSI)
- 372600 Btu/cu-ft LPG nominal capacity
- Single stage gas valve
Combination multi-function controls for a wide range of applications. the 36H combination gas control valve is a versatile multi-function control designed to meet the requirements for use with intermittent ignition systems (direct ignition, proven pilot, HSI). 36H is our highest capacity combination gas valve.
| Type | Gas Valve |
| Coil Voltage | 24 V |
| Domestic/Import | Import |
| Gas Type | Liquid Propane/Natural Gas |
| Ignition Type | HSI/DSI/Intermittent/Proven Pilot |
| Nominal Capacity | 230000 Btu/cu-ft |
| Nominal Size | 1/2 x 3/4 in |
| Pressure Rating | 0.5 psi |
| Series | 36H |
| Temperature Rating | -40 to 175 deg F |
| Brand | White-Rodgers™ |
| UNSPSC | 40141650 |
| Country of Origin | MX |
| Manufacturer | Emerson Electric |
| UPC | 786710535185 |
| Manufacturer Part Number | 36H32-304 |
1/4 in OD Pilot Fitting, LP Conversion Kit, 1/2 x 3/4 in and 1/2 x 3/8 in Bushings
CSA Certified
