Double Check Backflow Device, 6 in, Flange, 304/304L Stainless Steel
PartDER6020GOSY
MFGD-6020G
Description
Ames Fire & Waterworks® Check Valve Assembly, Lead-Free Double, Series: Deringer™20G, 6 in Nominal, Grooved End Style, 10 to 175 psi Pressure, 125 lb Pressure Class, 33 to 140 deg F, Outside Yoke and Stem Ball Valve/Gate Valve, Double Check Valve Backflow, Media: Water, 304 Stainless Steel Body, 39.9 in L x 12 in W Dimensions
Price/Availability Accessible On Login
- Resiliently seated and inline OSY shutoff valves
- Pre-wired supervisory switches
- Tamper-resistant test cocks
- Dual-Action check modules for low and high flow performance
- Bow-seal full access cover for lower weight and easy access to valve internals
Ames Deringer™ 20 and 20G double check valve assemblies are designed to prevent non-health hazard pollutant from entering the potable water supply system caused by backpressure and/or backsiphonage condition. Deringer™ 20 feature integral Eccentric-seal™ butterfly shut-off valve for a short lay length and Dual-action™ check for high performance at low and high flow rate. Deringer™ 20G also feature Dual-action™ check, but with OS and Y shut-off valve. Either may be installed under continuous pressure service to protect against both backpressure and backsiphonage. Maximum working pressure is 175 psi.
| Type | Double Check |
| Series | 20 |
| Nominal Size | 6 in |
| End Style | Flange |
| Body Material | 304/304L Stainless Steel |
| Backflow Type | Double Check |
| Ball Valve/Gate Valve Type | Outside Yoke and Stem |
| Dimensions | 39.9 in L x 12 in W |
| Media | Water |
| Pressure Class | 125 lb |
| Pressure Rating | 175 psi |
| Temperature Rating | 33 to 140 deg F |
| Brand | Ames Fire & Waterworks® |
| UNSPSC | 40141600 |
| Alternate Part Number 1 | DERINGER 20G 6 |
| Country of Origin | US |
| Manufacturer | Watts Water Technologies |
| UPC | 737733034902 |
| Manufacturer Part Number | D-6020G |
1 year Limited
ANSI B16.1|ASSE 1015|AWWA C510-07|cULus Listed|FM Approved|NSF/ANSI 372|USC Certified|PROP65: This product can expose you to chemicals including lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
